Tips for Troubleshooting pool heaters

by brittney_cutler_2 | June 29, 2022 8:00 am

[1]
Troubleshooting pool heaters is not rocket science; however, it does take experience and several specific tools. Photos courtesy Patriot Pool Heating Co.

Using process of elimination to diagnose and repair heating equipment

By Tom Soukup

Troubleshooting pool heaters is not rocket science; however, it does take experience and several specific tools. Companies with a background in residential and commercial boiler systems must be well-equipped, and technicians should be well-trained to install, diagnose, and repair a variety of gas-fired equipment. Since pool water heaters are only one portion of the industry, some technicians may find themselves working on heating equipment in which they do not have the right tools to carry out the job properly.

Aside from the pool heater manufacturer’s installation and operation manual, the two most important tools for diagnosing heater issues are a multimeter, which allows a technician to check voltage and resistance, and a gas monometer for checking gas or liquid petroleum (LP) pressure. These are the essential minimum requirements for any professional pool heater service technician to have when on a troubleshooting call.

Upon arriving to the facility

When a service technician is sent out on a troubleshooting visit, the first thing they should do is inspect the installation of the heating equipment to make sure it meets the manufacturer’s requirements in addition to the local prevailing code requirements.

[2]
This heat exchanger failed after one year due to condensate, which resulted from incorrect flow and incorrect gas supply.

Technicians should then ask the customer what the issue or complaint is. Further, it is important techs also ask the client if other people have looked at it and, if so, what work have they performed. The initial inspection, along with the answers to these questions, will help technicians gather the information needed to direct their diagnosis.

For instance, if the heater does not come on, no lights are illuminated, and the display screen is blank, the prognosis is an electrical issue. When faced with this problem, technicians should check the circuit breakers, as well as to see if the heater is on a timer or if it is also included as part of an automation system. If all these things are absent or functioning, the next step is determining if there is voltage at the heater. If there is, this is when a technician should refer to the manual to begin the rest of the troubleshooting procedure.

If the heater is on but will not fire, the problem could be caused by a fuel supply issue. Although it can still be an electrical problem, technicians should start by inspecting the fuel supply. If the heater uses propane, check to make sure the tank has sufficient fuel. If it uses gas or LP, check to make sure all valves are open.

After performing these basic checks, a technician must ensure there is sufficient water flow through the heat exchanger. In doing this, make sure the pump is running and, if not, determine why.

Heaters either have a pressure switch or a flow switch to ensure flow is established. To protect the heat exchanger, most heaters will not fire if water flow is not established. As a result, low flow can be attributed to clogged filters or valves in the wrong position.

Power, fuel, and water flow are the external requirements that must be met first. If these needs are met and the issue prevails, it is now time for the technician to troubleshoot the heater.

[3]
This is a heater that failed after two years because of incorrect venting and piping.

Checking for fuel supply issues

If the heater runs through its cycle but will not ignite, it is likely there is a more complicated fuel supply issue.

The number one issue many technicians find in the field with malfunctioning pool heaters is the use of undersized gas piping. Most installation and operation manuals provide gas piping sizes based on the capacity of the unit and the distance from the heater to the fuel source, whether it is an LP tank or a natural gas meter.

Gas systems are designed on pressure and distance. It is worth noting, by distance it means developed pipe length. This represents the length of the pipe including the pressure drop created by elbows and other fittings. A technician can determine whether the size and length of the gas piping is adequate by reading the installation and operation manual.

Further, it is critical to verify the gas valve inside the unit is functioning properly; therefore, technicians should check to ensure there is voltage going to the valve. If voltage is detected, it means all other safety devices in the unit are functioning as intended.

[4]
Flame rollout, due to condensate dripping on the burner, has resulted in soot and scorched components. This damage occurred in less than two years.

At this point, a monometer must be used to verify there is incoming gas pressure to the valve. Some valves allow a technician to check the manifold pressure to verify there is sufficient pressure on the burner side of the valve. All these values are unit-specific and will be outlined clearly in the manual.

In the event the gas valve opens and there is sufficient pressure, yet the heater still fails to ignite, sputters, or runs for a brief period before shutting down, the control is not seeing establishment of flame (flame proving). This could either be the result of a defective flame sensor or an insufficient gas supply. Simply verifying there is sufficient gas pressure at the burner at one moment in time is not enough for a technician to say with certainty that gas supply is not the issue.

[5]
Whoever worked on this system did not know how to fix the low water issue. They bypassed the low water cutoff control which resulted in a burnt-up heater.

The ladder chart in the manual will show both static and dynamic gas pressure must be verified. Checking static gas pressure must be completed while all other appliances on the same gas supply are running at the same time, but with the pool heating unit off. Checking dynamic gas is the same as static, except the pool heating appliance will be turned on.

If the dynamic gas pressure drops below manufacturer requirements at any point, this suggests the issue is an undersized piping system, regulator, or meter. Just because most heaters have a 19-mm (0.75-in.) gas pipe connection does not mean 19 mm is sufficient of the developed length of pipe.

Technicians should always ask the client about any changes on the property that could cause the problem at hand. Even small additions to the load on a gas meter can be the culprit, such as installing a larger gas range, or adding a gas fireplace or outdoor fire pit

Like in the 1983 movie, A Christmas Story, just because one has an electrical outlet, it does not mean they can simply continue to plug in more lights. The same applies for gas meters.

[6]
It is a code violation to have unions inside pool heater cabinets.

In fact, many times, gas supply issues can only be fixed by increasing the pipe size or pressure. To do either, a licensed gas professional is required to replace the necessary components.

Evaluating the power supply

Electrical issues are often the result of work done on the property, such as the addition of outdoor lighting. Any changes or additions can create a variable; therefore, a technician should try to eliminate these variables before diving into a deeper diagnosis.

If power is delivered to the heater properly, and the unit is not functioning as intended, most heaters have some form of built-in diagnosis displayed on the control interface. The display may report there is a sensor error, or where the error stems from. However, technicians must keep in mind, a sensor error does not mean with certainty the sensor is bad. In many cases, the sensor is doing its job exactly as it is designed for the safety of the system.

[7]
This heat exchanger failed in less than two years due to condensate issues.

This is another reason it is critical to have the installation and operation manual, which will show the probable causes of a specific sensor error. A technician should work through the manual and use process of elimination to determine the source of the sensor error.

Testing system water flow

Flow is one of the simpler issues to diagnose. As previously mentioned, the heating unit will be equipped with a pressure or a flow switch to ensure flow is established. If flow is not present, the unit will not fire.

The most frequent cause of a low- or no-flow situation is clogged filters. The second most common issue is an inoperable or underperforming pump.

[8]
Fixing pool heating systems is best done via process of elimination.

If these issues are presenting, technicians should clean the filter, check the pump, and consult the heater manual to determine what the correct flow rate through the heat exchanger is. This should be checked against a flow meter on the effluent side of the heat exchanger. If there is insufficient flow, the piping system may not be designed or installed correctly, or the pump is undersized. One way to avoid this is by installing variable-frequency drive (VFD) powered booster pumps on all pool heating systems, so the filter and heater loops are hydraulically separated.

Much like diagnosing any mechanical problem, fixing pool heating systems is best done via process of elimination. It takes time, it takes the right tools, and it takes the appliance manual. An experienced technician also helps expedite the process.

Author

Tom Soukup is the principal of Patriot Pool Heating Co., with over 20 years as a hydronic designer and installer. He specializes in high-efficiency and green technology and brings his expertise to custom commercial work, pool heating, and agricultural projects. Soukup can be reached at twsoukup@patriotpoolheating.com
